Luoyang Lutong Heavy Industry LTS212H 12-ton hydraulic single drum road roller: specifications, images, introduction, and parts details

LTS212H 800x800 背景图 6.jpg

LTS212H Hydraulic rear driver vibratory roller is manufactured according to the international advanced technology and by use of imported components from abroad. The machine is super heavy-duty vibratory roller, possesses a great working mass and strong centrifugal force. It is the best compaction equipment of high quality and high effect in the large-scale mechanized construction. This machine is suitable for non-cohesive materials, such as graves,macadam, macadam-aggregate mixtures and sandy soil etc. Also it can effect good compaction in cohesive material, There-fore the machine an ideal equipment for expressway. mining road, embankment, sea port and industrial sites.

Main Ch

LTS212H 800x800 背景图 4.jpg

aracteristic:

1,Power System: CUMMINS turbocharged diesel engine, have high coefficient power reserve. Which comply with the operating condition above 4000 meters altitude

2,Full hydraulic and double drive, Hydraulic vibration,Hydraulic articulated steering,advanced technology,Blocking the oil supply to Brake the vehicle,safe and reliable.

3,Streamline outline, circular windshield glass and curvy hood form a unique style.

4,Hydraulic system are of the 90 series made by American manufacturer DANFOSS

6,Equipped with padfoot or removal padfoot as option

Main Technical parameters

Model	LTS212H
Operating mass	12000kg
Static linear load	286N/cm
Vibration amplitude	1.6/0.8mm
Centrifugal force	260/160Kn
Vibration frequency	29/35Hz
Travel speed	0-10.2Km/h
Ground clearance	360mm
Electrical voltage	24V
Tire size	17.5-25
Grade ability	30%
Turning radius	7000mm
Overall dimension (LxWxH)	5610x2280x3000mm
Drum rim thickness	24mm
Drum width	2100mm
Wheel base	3060mm
Diesel engine power	110/2300rpm
Diesel engine model	CUMMINS6BT5.9
Fuel tank capacity	220L
Hydraulic tank capacity	160L
Driving system	DANFOSS
Ship	1 unit/40HQ 3units/2x40HQ
